Well Control Panels
CU-W-1004
Well Intervention Control Unit with a Pump ratio of 60:1,a Pump displacement of 0.67 cubic inches per stroke and a main system max rated working pressure of 3,000 psi
CU-W-1013
Well Intervention Control Unit with a 250 litre reservoir and a Cutter valve system with 74 litre accumulator storage and a Gate valve system with 47 litre accumulator storage
CU-W-1014
Well Intervention Control Unit with an Upper BOP : 3000 psi, a Lower BOP : 3000 psi, a Stuffing box : 1500 psi (hand pump operation), a 20 litre accumulator connected to these functions, a Reservoir 35 litre / 7.5 imperial gallon capacity and a Single air hydro pump and a Hand pump back-up
CU-W-1015
Well Intervention Control Unit with Wireline system control functions which include: Upper BOP : 3,000 psi, Middle BOP : 3,000 psi, Lower BOP : 3,000 psi (with ESD "shear seal" function), Tool catcher : 3,000 psi, Stuffing box : 1,500 psi (hand pump operation), 20 litre accumulator connected to these functions and a Reservoir 65 litre / 14 imperial gallon capacity
CU-W-1016
Well Intervention Control Unit which has Wireline system control functions which include: Upper BOP : 3,000 psi, Lower BOP : 3,000 psi, Stuffing box : 1,500 psi (hand pump operation), 37 litre accumulator connected to these functions, Reservoir 70 litre / 15 imperial gallon capacity and a Single air hydro pump
CU-W-1019
Well Intervention Control Unit with Wireline system control functions which include: Upper BOP : 5,000 psi, Middle BOP : 5,000 psi, Lower BOP : 5,000 psi (with ESD "shear seal" function,), Stuffing box : 1,500 psi (hand pump operation), 20 litre accumulator connected to these functions, Reservoir 65 litre / 14 imperial gallon capacity and a Single air hydro pump
CU-W-1020
Well Intervention Control Unit with a Wireline system control functions which include an Upper BOP : 3,000 psi, Middle BOP : 3,000 psi, Lower BOP : 3,000 psi (with ESD "shear seal" function), Tool catcher : 3,000 psi, Stuffing box : 1,500 psi (hand pump operation), 20 litre accumulator connected to these functions, and a Reservoir 65 litre / 14 imperial gallon capacity
CU-W-1022
Well Intervention Control Unit with a Wireline system control functions whcih include an Upper BOP : 3,000 psi, Middle BOP : 3,000 psi, Lower BOP : 3,000 psi (with ESD "shear seal" function), Tool catcher : 3,000 psi, Stuffing box : 1,500 psi (hand pump operation), 25 litre accumulator connected to these functions and a Reservoir 65 litre / 14 imperial gallon capacity
CU-W-1023
Well Intervention Control Unit includes Wireline system control functions: Upper BOP : 3,000 psi, Lower BOP : 3,000 psi, Stuffing box : 1,500 psi (hand pump operation), 20 litre accumulator connected to these functions, Reservoir 65 litre / 14 imperial gallon capacity, and a Single air hydro pump
CU-W-1024-1
Well Intervention Control Unit with Lubricator system control functions which include Open : 11,500 psi, Closed : 11,500 psi, Reservoir 65 litre / 14 imperial gallon capacity and a Single air hydro pump
