Hand Portable Control Units
CU-B-1001
Dual Hydraulic BOP Pump is fitted with a stainless steel fluid reservoir tank, has a maximum system rated pressure of 3,000 psi, and has 4 lines.
CU-B-1002
Hand Portable Dual BOP Control Unit is fitted with a 10l stainless steel fluid reservoir tank, has a maximum pressure rating of 5000 psi and weighs just 21 kgs.
CU-P-1004
Hand Portable Hydraulic Control Pump Unit is fitted with a stainless steel 9.75 litre 2.1 gallon fluid reservoir tank, has a maximum pressure rating of 5000 psi and weighs just 48 kgs.
CU-P-1006
Hand Portable Hydraulic Control Pump Unit is fitted with a supply and a return reservoir both made from HDPE plastic, they each have a capacity of 9 litres (1.98 gallon), has a maximum system pressure rating of 5,000 psi, has 1 line and weighs just 48 kgs.
CU-T-1003
10k Single Pressure Test Pump is fitted with a stainless steel 5 gallon fluid reservoir tank, has one supply line and a maximum rated working pressure of 10,000 psi and weighs just 50 kg.
CU-W-1017
Hand Portable Well Control Unit with a Pneumatic Master Valve: Regulated 0-100 psi, a Higher Master valve: Regulated 0-5,000 psi and an SSSV: Pump regulated supply 0-10,000 psi. This unit has a 20 litre tank capacity
